395nm激光器| Central wavelength (nm)波長 | 395±5 |
| Output power@3.3VDC (mW, CW)功率 | > 80 (Power adjustable by software) |
| Power stability (rms, over 4 hours)穩定性 | <3% |
| Pulse width (FWHM)脈寬 | > 10ns, 20ns, … , 10ms |
| Transverse mode輸出模式 | Near TEM00 |
| Noise of amplitude(rms, CW)性噪比 | < 1% |
| M2 factor光束質量 | < 1.2 |
| Beam diameter at the aperture ( 1/e2,mm)光斑 | ~ 1.2 |
| Beam divergence, full angle (mrad)發散角 | < 1 0 |
| Polarization ratio偏振比 |
>50:1 (>100:1, optional) Horizontal±5 degree (Vertical Optional) |
| User trigger frequency (Multifunctional Pulse Trigger optional)脈寬 |
1Hz- 10MHz ( 1Hz- 10MHz by using CNI Multifunctional Pulse Trigger) |
| Rise Time (ns) 上升時間 | <4 |
| Fall Time (ns)下降時間 | <3 |
| Modulation Depth (extinction ratio) | > 1000000:1 |
| Warm-up time (minutes)上升溫度 | <5 |
| Beam height from base plate (mm)中心高 | 19 |
| Operating temperature (C)工作溫度 | 10~35 |
| Input voltage電壓 | + 12VDC |
| Expected lifetime (hours)壽命 | 10000 |
| Warranty保修 | 1 year |
