Output power@3.3VDC (mW, CW)功率

> 50

Power stability (rms, over 4 hours)功率穩(wěn)定性

<3%

Pulse width (FWHM)脈寬

> 10ns, 20ns, … , 10ms

Transverse mode輸出模式

Multimode

Noise of amplitude(rms, CW)性噪比

< 1%

Beam diameter at the aperture ( 1/e2,mm)光斑

< 1.5×3.5

Beam divergence, full angle (mrad)發(fā)散角

~2.3×0.2

Polarization ratio偏振比

>50:1

User trigger frequency 頻率

1Hz-10MHz

Rise Time (ns)上升沿

<4

Fall Time (ns)下降沿

<3

Modulation Depth (extinction ratio)

> 1000000:1

Warmup time (minutes)上升時間

<5

Beam height from base plate (mm)中心高

19

Operating temperature (C)工作溫度

10~35

Input voltage供電電壓

+ 12VDC

Expected lifetime (hours)壽命

10000

Warranty保修

1 year
