335nm激光器| Wavelength (nm)波長 | 335± 1 |
| Operating mode工作方式 | Electro-optic Q-switched |
| Average power (W)平均功率 | 1~ 1000mW ( 1W@ 10kHz) |
| Average power (W) = Single pulse energy (mJ) * Rep. rate (kHz) | |
| Single pulse energy ( µJ)單脈沖能量 | 1~ 100( 100μJ @ 10kHz) |
| Rep. rate (kHz)頻率 | 10 |
| Pulse duration (ns)脈寬 | ~4 @ 10kHz |
| Peak power (kW)峰值功率 | 1~25 (25kW@ 10kHz) |
| Ave power stability (over 4 hours)功率穩定性 | <3%, <5% |
| Warm-up time (minutes)預熱時間 | < 10 |
| Beam divergence, full angle (mrad)發散角 | <3 |
| Beam diameter at the aperture ( 1/e2,mm)光斑 | ~ 1.5 |
| Beam height from base plate (mm)中心高 | 79 |
| Cooled method制冷 | Air cooled |
| Operating temperature (C)工作溫度 | 10~35 |
| Power supply (220/ 110VAC)供電 | 220v可調 |
| Expected lifetime (hours)壽命 | 10000 |
| Warranty period保修 | 1 year |
