266nm激光器| Wavelength (nm)波長 | 266± 1 | |
| Operating mode工作方式 | Pulsed | |
| Output power (mW)功率 | 10@ 1MHz | 50@ 1MHz |
| Power stability (rms, over 4 hours)功率穩定性 | <5%, <3% | |
| Pulse width (ps)( 1)脈寬 | One fixed value between 50~900ps | |
| M2 factor光束質量 | <2 | |
| Repetition frequency(MHz)(2) | One fixed value between 0. 1-20MHz | |
| Polarization ratio偏振比 | > 15dB | |
| Warm-up time (minutes)上升溫度 | < 15 | |
| Beam height from base plate (mm)中心高 | 40 | |
| Delivery cable length(cm) | 60 | |
| Operating temperature (C)工作溫度 | 15~35 | |
| Power supply供電 | 220V AC/ 12V DC | |
| Expected lifetime (hours)壽命 | 10000 | |
| Warranty保修 | 1 year | |
| Options |
( 1) Pulse width 50~900ps variable or <50ps can be customized. (2) Repetition rate 0. 1~20MHz variable or 1Hz~1kHz can be customized. RS 232 interface Higher output power can be customized |
|
