228nm激光器

產品說明：228nm脈沖激光器 LD PUMPED ALL-SOLID-STATE EOM Q-SWITCHED LASER AT 228 nm All solid state EOM Q-switched laser at 228 nm has the features of high peak power high repetition rate and short pulse duration which is widely used in marking

訂購熱線：0431-81759561

產品詳細

228nm脈沖激光器
LLQ228-40mw

LLQ228-40mw全固態213 nm的紫外激光器廣泛用于紫外光固化，微電子，光盤雕刻，激光醫療，科學實驗等

Wavelength (nm)	228± 1
Operating mode	Electro-optic Q-switched
Average power (W)	1~40mW (40mW@ 10kHz)
Average power (W)	Average power (W) = Single pulse energy (mJ) * Rep. rate (kHz)
Single pulse energy ( µJ)	1~4 (4µJ @ 10kHz)
Rep. rate (kHz)	10
Pulse duration (ns)	~4 @ 10kHz
Peak power (kW)	~ 1 ( 1kW@ 10kHz)
Ave power stability (over 4 hours)	<3%, <5%
Warm-up time (minutes)	< 10
Beam divergence, full angle (mrad)	<5
Beam diameter at the aperture ( 1/e2,mm)	<8
Beam height from base plate (mm)	79
Cooled method	Water cooled
Operating temperature (C)	10~35
Power supply (220/ 110VAC)	PSU-AOM (3U)
Expected lifetime (hours)	10000
Warranty period	1 year
