577nm激光器

577nm激光器

產品說明：577nm激光器 LL577-3500mw LD PUMPED ALL-SOLID-STATE YELLOW LASER AT 577nm All solid state 577 nm yellow laser is made features of ultra compact long lifetime and easy operating which is widely used in collimation laser medical treatmen
訂購熱線：0431-81759561
  • 產品詳細
577nm激光器
LL577-1200mw


LD PUMPED ALL-SOLID-STATE YELLOW LASER AT 577nm All solid state 577 nm yellow laser is made features of ultra compact, long lifetime and easy operating, which is widely used in collimation, laser medical treatment, scien

Part number LL577-1200mw
Wavelength (nm) 577±2
Operating mode CW
Output power (mW) 600- 1200
Power stability (rms, over 4 hours) <3%, <2%, < 1%
Transverse mode Multi mode
M2 factor <2.0
Beam diameter at the aperture ( 1/e2, mm) <2.5
Beam divergence, full angle (mrad) < 1.5
Polarization Ratio > 100:1, (Horizontal or Vertical Optional)
Warm-up time (minutes) <5
Pointing stability after warm-up (mrad) <0.05
Beam height from base plate (mm) 27.4
Operating Temperature (°C) 10-35
Modulation option TTL on/off, 1Hz- 1kHz, 1kHz- 10kHz
Power supply (90-264VAC) PSU-H-LED
Expected lifetime (hours) 10000
Warranty 1 year
