607nm激光器

607nm激光器

產品說明：607nm激光器 LL607-400mw LD PUMPED ALL-SOLID-STATE RED LASER AT 607nm DPSS red laser at 607nm is made features of ultra compact long lifetime and easy operating which is widely used in measurement spectrum analysis as the substitute fo
訂購熱線：0431-81759561
  • 產品詳細
607nm激光器
LL607-400mw

LD PUMPED ALL-SOLID-STATE RED LASER AT 607nm DPSS red laser at 607nm is made features of ultra compact, long lifetime and easy operating, which is widely used in measurement, spectrum analysis as the substitute for He-Ne lasers.

Part number LL607-400mw
Wavelength (nm) 607±3
Operating mode CW
Output power (mW) 1-400
Power stability (rms, over 4 hours) <3%, <2%, < 1%, 0.5%
Transverse mode TEM00
M2 factor < 1.2
Beam diameter at the aperture ( 1/e2, mm) <2.0
Beam divergence, full angle (mrad) < 1.5
Polarization Ratio > 100:1, (Horizontal or Vertical Optional)
Warm-up time (minutes) <5
Pointing stability after warm-up (mrad) <0.05
Beam height from base plate (mm) 27.4
Operating Temperature (°C) 10-35
Modulation option TTL on/off, 1Hz- 1kHz, 1kHz- 10kHz,
Power supply (90-264VAC) PSU
Expected lifetime (hours) 10000
Warranty 1 year
