PICOSECOND PULSED BLUE DIODE LASER AT 450nm
It features integrated electronics, repetition rate 100kHz to 80MHz, synchronized signal output. Fast ON/ OFF/ multiplexing capability. Suitable for fluorescence excitation, time resolve spectrum, highly sensitive absorption spectroscopy, etc.

Central wavelength (nm) 中心波長	450±5
Operating mode 輸出方式	Pulsed
Peak power (mW)輸出功率	1~60
Power stability (rms, over 4 hours) 功率穩(wěn)定性	<1%, <2%, <3%
Pulse width (ps) 脈寬	100~1000 (unadjustable)
Transverse mode 輸出模式	Near TEM00
User trigger frequency頻率	100kHz~20MHz (Internal trigger available)	20MHz~80MHz
Beam diameter at the aperture (1/e2, mm)光斑尺寸	~1.2
Beam divergence, full angle (mrad)發(fā)散角	~1.0
Warm-up time (minutes)上升時(shí)間	<5
Beam height from base plate (mm)中心高	26.5
Operating temperature (℃)工作溫度	10~35
Operating voltage電壓	DC12V 4A
Warranty保修期	1 year
