Operating mode工作方式

Pulsed

Peak power (mW)功率

1~ 100

Power stability (rms, over 4 hours)功率穩(wěn)定性

<3%

Pulse width (ps)脈寬

100~ 1000 (unadjustable)

Transverse mode 光斑模式

Near TEM00

User trigger frequency 頻率

100kHz~20MHz

Beam diameter at the aperture (1/e2, mm) 光斑尺寸

1.2

Beam divergence, full angle (mrad) 發(fā)散角

1.0

Warm-up time (minutes) 預熱

<5

Beam height from base plate (mm)中心高

26.5

Operating temperature (℃)工作溫度

10~35

Operating voltage 供電

DC12V 4A

Warranty保修

1 year
