Operating mode工作方式

CW

Output power (mW)輸出功率

>200

Power stability (rms, over 4 hours) 25℃功率穩定性

 <3%

Transverse mode 光斑模式

TEM00

Ellipticity

>0.95

M2 factor 光束質量

<1. 1

Beam diameter at the aperture (1/e2,mm)光斑尺寸

1.0

Beam divergence, full angle (mrad) 發散角

<1.5

Warm-up time (minutes)預熱

<5

Beam height from base plate (mm)中心高

25

Operating temperature (℃) 工作溫度

25+/-3

Power supply (85-264VAC)供電

220v可調

TTL / Analog modulation調制

TTL 1kHz-10kHz

Expected lifetime (hours)壽命

10000

Warranty保修

1 year
